Cartridge Filter, with cartridges as filter elements, are applicable to precision filtration of liquid to remove traces of tiny impurities and bacteria. They have the advantages of high accuracy, high efficiency and large capacity. Cartridge Filter are equipped with folding cartridges, melt-blown cartridges, wire-wound cartridges, ceramic filters and metal powder sintered cartridges to meet the requirements of all kinds of conventional and special precision filtration.

Main Technical Parameters

■ Optional cartridges: melt-blown cartridges, wire-wound cartridges, folding cartridges, metal cartridges, ceramic cartridges, metal powder sintered cartridges and polyether sulfone

■ Optional accuracy (um): 0.05-200

■ Core length (inch): 10, 20, 30, 40 and 60

■ Number of cartridges of single filter: 1-200

■ Casing material: 304, 316L and CS

■ Applicable viscosity (cp): 1-500

■ Design pressure (MPa): 0.6, 1.0, 1.6 and 2.0
